| Test programmes: | Idle Test, Compression, Starter test, Ignition Angle, Battery test |
| Ignition Scope: | Primary: 5...500V |
| Secondary: 5...50KV | |
| Universal Oscilliscope: | 5...50MV/div; |
| 1...50V/div | |
| 12 Channel Oscilliscope: | ±1...±500V |
|
1 Channel Multimeter
| |
| Voltage: | ±5V...±50V |
| Current: | ±1A...±500A |
| Resistance: | 200 Ω / 2k Ω / 20k Ω / 200k Ω / 2M Ω |
| Frequency: | up to 200KHz |
| Power Supply: | 8-36 V DC (42 V DC prepared) |
| Weight: | 3.5kg |
| Dimensions: | 270 x 85 x 320 mm |
